Long before we had internet newsfeeds or Twitter, Ceefax delivered up-to-the-minute news right to your television screen. Launched by the BBC in 1974, Ceefax was the world’s first teletext service, offering millions of viewers a mix of news, sports, weather, and entertainment on demand. Fast forward 50 years, and the iconic service is being honored with a special exhibition at the Centre for Computing History in Cambridge . At its peak, Ceefax reached over 22 million users. [Ian Morton-Smith], one of Ceefax’s original journalists, remembers the thrill of breaking stories directly to viewers, bypassing scheduled TV bulletins. The teletext interface, with its limited 80-word entries, taught him to be concise, a skill crucial to news writing even today. We’ve talked about Ceefax in the past, including in 2022 when we explored a project bringing Ceefax back to life using a Raspberry Pi . Prior to that, we delved into its broader influence on early text-based information systems in a 202...

YouTuber [MechPanda] has recreated a DIY STM hack we covered about ten years ago, updating it to be primarily 3D-printed, using modern electronics, making it much more accessible to many folks. This simple STM setup utilises a piezoelectric actuator constructed by deliberately cutting a piezo speaker into four quadrants. With individual drive wires attached to the four quadrants. They (re)discovered that piezoelectric ceramic materials are not big fans of soldering heat. Still, in the absence of ultrasonic welding equipment, they did manage to get some wires to take to the surface using low-temperature solder paste. As you can tell, you can only image conductive samples They glued a makeshift probe holder on the rear side of the speaker actuator, which was intended to take a super sharp needle-like piece of tungsten wire. Putting the wire in tension and cutting at a sharp angle makes it possible with many attempts to get some usable points. Usable, in this instance, means sharp d...

When you think 1080p video, you probably don’t think STM32 microcontroller. And yet! [Gabriel Cséfalvay] has pulled off just that through the creative use of on-chip peripherals. Sort of. The build is based around the STM32L4P5—far from the hottest chip in the world. Depending on the exact part you pick, it offers 512 KB or 1 Mbyte of flash memory, 320 KB of SRAM, and runs at 120 MHz. Not bad, but not stellar. Still, [Gabriel] was able to push 1080p at a sort of half resolution. Basically, the chip is generating a 1080p widescreen RGB VGA signal. However, to get around the limited RAM of the chip, [Gabriel] had to implement a hack—basically, every pixel is RAM rendered as 2×2 pixels to make up the full-sized display. At this stage, true 1080p looks achievable, but it’ll be a further challenge to properly fit it into memory. Output hardware is minimal. One pin puts out the HSYNC signal, another handles VSYNC. The same pixel data is clocked out over R, G, and B signals, making all t...

It can often feel like modern devices are less hackable than their thicker and far less integrated predecessors, but perhaps it’s just that our techniques need to catch up. Here’s an outstanding hack that adds a dual SIM slot to a US-sold eSIM iPhone 15/15 Pro, while preserving its exclusive mmwave module. No doubt, making use of the boardview files and schematics, it shows us that smartphone modding isn’t dead — it could be that we need to acknowledge the new tools we now have at our disposal. When different hardware features are region-locked, sometimes you want to get the best of both worlds. This mod lets you go the entire length seamlessly, no bodges. It uses a lovely looking flexible printed circuit (FPC) patch board to tap into a debug header with SIM slot signals, and provides a customized Li-ion pouch cell with a cutout for the SIM slot. There’s just the small matter of using a CNC mill to make a cutout in the case where the SIM slot will go, and you’ll need to cut a buried...

We love the idea [Btoretsukuru] shared that uses a simple setup called the Syringe Slider to take smoothly-tracked video footage of small scenes like model trains in action. The post is in Japanese, but the video is very much “show, don’t tell” and it’s perfectly clear how it all works. The results look fantastic! Suited to filming small subjects. The device consists of a frame that forms a sort of enclosed track in which one’s mobile phone can slide horizontally. The phone butts up against the plunger of an ordinary syringe built into the frame. As the phone is pushed along, it depresses the plunger which puts up enough resistance to turn the phone’s slide into a slow, even, and smooth glide. Want to fine-tune the resistance and therefore the performance? Simply attach different diameter tips to the syringe. The results speak for themselves, and it’s a fantastically clever bit of work. There are plenty of DIY slider designs (some of which get amazingly complex ) but they are ra...

Some hackers have the skills to help us find noteworthy lessons in even the most basic of repairs. For instance, is your computer failing to boot? Guess what, it could just be a flash chip that’s to blame — and, there’s more you should know about such a failure mode. [Manawyrm] and [tSYS] over at the Kittenlabs blog show us a server motherboard fix involving a SPI flash chip replacement, and tell us every single detail we should know if we ever encounter such a case. They got some Gigabyte MJ11-EC1 boards for cheap, and indeed, one of the BIOS chips simply failed — they show you how to figure that one out. Lesson one: after flashing a SPI chip, remember to read back the image and compare it to the one you just flashed into it! Now, you might be tempted to take any flash chip as a replacement, after all, many are command-compatible. Indeed, the duo crew harvested a SPI chip from an ESP32 board, the size matched, and surely, that’d suffice. That’s another factor you should watch out...

There was movement in the “AM Radio in Every Vehicle Act” last week, with the bill advancing out of the US House of Representatives Energy and Commerce Committee and heading to a full floor vote. For those not playing along at home, auto manufacturers have been making moves toward deleting AM radios from cars because they’re too sensitive to all the RF interference generated by modern vehicles. The trouble with that is that the government has spent a lot of effort on making AM broadcasters the centerpiece of a robust and survivable emergency communications system that reaches 90% of the US population. The bill would require cars and trucks manufactured or sold in the US to be equipped to receive AM broadcasts without further fees or subscriptions, and seems to enjoy bipartisan support in both the House and the Senate. Critics of the bill will likely point out that while the AM broadcast system is a fantastic resource for emergency communications, if nobody is listening to it when ...

Hardware restrictions can be unreasonable, and at times, it can be downright puzzling just how arbitrary they are. Such is the case with the Lenovo ThinkPad 13 — it’s got a M.2 M-key socket, yet somehow only supports SATA SSDs in it, despite the CPU being new enough to support both SATA and NVMe effortlessly. [treble] got one of those laptops from a recycler, and decided to figure out just what this laptop’s deal is. Armed with schematics, she and her friend looked at the M.2 implementation. The slot’s schematic sure looked ready to support either kind of drive, a surprising find. Here’s the catch — Lenovo only populated components for SATA drive support. All you need to switch from SATA to NVMe support is three magnet wire jumpers, or zero-ohm 0402 resistors, and voila; you can now use the significantly cheaper kind of M.2 drives in your ThinkPad. All is documented, and [treble] even mentions that you could increase the link speed by adding more PCIe lane capacitors that Lenovo, a...

If your memory of slot cars as a childhood toy is of lightweight controllers with wire-wound rheostats inside, then you’re many years behind the state of the art when it comes to competitive slot car racing. In that world the full force of modern electronics has been brought to keeping the car on the road, and as an example here’s [Maker Fabio] with a cutting edge controller that has an ESP32 at its heart . It’s obvious that a huge amount of attention has gone into both the physical design of the unit and its software, and the result speaks for itself. The trigger sits on a proper bearing, and the sensor is a Hall-effect device on the PCB. The firmware was written in the Arduino IDE, and through the trigger and a rotary encoder all of its options can be configured on a small OLED display. Individual settings can be configured for each car, and we’re treated to a full explanation of this in the video. We are told that the files for both software and hardware will be released in due c...

The truth is, our desktop computers today would have been classed as supercomputers only a few decades ago. There was a time when people who needed real desktop power looked down their noses at anyone with a Mac or a PC with any operating system on it. The workstation crowd used Sun computers. Sun used the Sparc processor, and the machine had specs that are laughable now but were enviable in their day. [RetroBytes] shows off Sun’s final entry in the category, the Ultra 45 from 2007 . Confusingly, the model numbers don’t necessarily increase. The Ultra 80, for example, is an older computer than the 45. Then there were machines like the Ultra 20, 24, 27, and 40 that all used x86 CPUs. A ’45 had one or two UltraSPARC III 64-bit CPUs running at 1.6 GHz and up to a whopping 16 GB of RAM (the one in the video has 8GB). Sure, we see less powerful computers today, but they are usually Chromebooks or very cheap PCs. The Ultra line started back in 1995 but went underground for a few years wit...

Sometimes you instantly know who’s behind a project from the subject matter alone. So when we saw this “aerial dog poop removal system” show up in the tips line, we knew it had to be the work of [Caleb Olson]. If you’re unfamiliar with [Caleb]’s oeuvre, let us refresh your memory. [Caleb] has been on a bit of a dog poop journey, starting with a machine-learning system that analyzed security camera footage to detect when the adorable [Twinkie] dropped a deuce in the yard. Not content with just knowing when a poop event has occurred, he automated the task of locating the packages with a poop-pointing robot laser . Removal of the poop remained a manual task, one which [Caleb] was keen to outsource, hence the current work. The video below, from a lightning talk at a conference, is pretty much all we have to go on, and the quality is a bit potato-esque. And while [Caleb]’s PoopCopter is clearly still a prototype, it’s easy to get the gist. Combining data from the previous poop-adjacent...

It’s a well-known secret that inkjet ink is being kept at artificially high prices, which is why many opt to forego ‘genuine’ manufacturer cartridges and get third-party ones instead. Many of these third-party ones are so-called re-manufactured ones, where a third-party refills an empty OEM cartridge. This is increasingly being done due to digital rights management (DRM) reasons, with tracking chips added to each cartridge. These chip prohibit e.g. the manual refilling of empty cartridges with a syringe, but with the right tweak or attack can be bypassed, with [Jay Summet] showing off an interesting HP cartridge DRM bypass using a physical man-in-the-middle-attack. This bypass takes the form of a flex PCB with contacts on both sides which align with those on the cartridge and those of the printer. What looks like a single IC in a QFN package is located on the cartridge side, with space for it created inside an apparently milled indentation in the cartridge’s plastic. This allows is ...

The software defined radio has opened up unimaginable uses of the radio spectrum for radio enthusiasts, but it’s fair to say that there’s one useful feature of an old-fashioned radio they lack when used via a computer. We’re talking of course about the tuning knob, because it represents possibly the most intuitive way to move across the bands. Never fear though, because [mircemk] has a solution. He’s converted a mouse into a tuning dial . The scroll wheel on a mouse is nothing more than a rotary encoder, and can easily be used as a sort of tuning knob. Replacing it with a better encoder gives it a much better feel, so that’s what he’s done. An enclosure has the guts of a mouse, with the front-mounted encoder wired into where the scroll wheel would have been. The result, for a relatively small amount of work, is a tuning knob, and a peripheral we’re guessing could also have a lot of uses beyond software defined radio. It’s not the first knob we’ve seen, for that you might want to sta...

[Ben] may be 15 years old, but he’s got the knack for 3D printing and artistic mechanical design. When you see his 3D-printed mechanical jellyfish lamp , we think you’ll agree. Honestly, it is hardly fair to call it a lamp. It is really — as [Ben] points out — a kinetic sculpture. One of the high points of the post is the very detailed documentation. Not only is everything explained, but there is quite a bit of background information on jellyfish, different types of gears, and optimizing 3D prints along with information on how to recreate the sculpture. There is quite a bit of printing, including the tentacles. There are a few options, like Arduino-controlled LEDs. However, the heart of the operation is a geared motor. All the design files for 3D printing and the Arduino code are in the post. There’s also a remote control. The design allows you to have different colors for various pieces and easily swap them with a screwdriver. One major concern was how noisy the thing would be wi...

These days everything needs to be connected to remote servers via the internet, whether it’s one’s TV, fridge or even that new car you just bought. A recently discovered (and already patched) vulnerability concerning Kia cars was a doozy in this regard, as a fairly straightforward series of steps allowed for any attacker to obtain the vehicle identification number (VIN) from the license plate, and from there become registered as the car’s owner on Kia’s network. The hack and the way it was discovered is described in great detail on [Sam Curry]’s website, along with the timeline of its discovery. Notable is that this isn’t the first vulnerability discovered in Kia’s HTTP-based APIs, with [Sam] this time taking a poke at the dealer endpoints. To his surprise, he was able to register as a dealer and obtain a valid session ID using which he could then proceed to query Kia’s systems for a user’s registered email address and phone number. With a specially crafted tool to automate the ent...

For some of us, the Speak ‘n Spell evokes pleasant memories of childhood as our first computer, along with one of those Merlin things. For others, it’s the ultimate circuit bending victim. For [Jeremy Geppert], they’re all-around good fun and he wanted to immortalize the device in a Simple Add-On (SAO) . This is [Jeremy]’s first board and SAO rolled into one, motivated by both Supercon and the SAO Contest. To start things off, [Jeremy] scaled down the design we all know and love to fit a 128×32 OLED display, and it looks great. The plan is to have the display, an amplified speaker, and a single button for input. Before committing the board order, [Jeremy] had a brief freak-out about the pin distance as it relates to the window for the OLED display. Luckily, his brother suggested checking things first by printing a 1:1 scale image of the board outline, and laying that over the display. This is the week it all comes together, as the tiny switches and (regular-size) connectors have ar...

Do you live in the UK, have a VCR and capture card, and an interest in Teletext? [James O’Malley] needs your help ! Teletext was, for many people around the world, their first experience of an electronic information system. The simple text and block graphics were transmitted on rotation as data bursts in the frame blanking periods of analogue TV broadcasts, and in an era of printed newspapers, they became compulsory reading. The UK turned off its old-style teletext over a decade ago with the switch to digital, but fragments of the broadcasts remain and can be painstakingly revived from period video recordings with the appropriate software. This is where [James’] problem begins. Having recovered a very large archive of 1980s and 1990s VHS tapes, he’s come to the realisation that he’s bitten off more than he can chew, and that the archive needs to be in the hands of an individual, entity, or organisation which can give it the resources necessary to archive both the teletext and the pro...

If you need an amplifier, [Hans Rosenberg] has some advice. Don’t design your own; grab cheap and tiny RF amplifier modules and put them on a PCB that fits your needs. These are the grandchildren of the old mini circuits modules that were popular among hams and RF experimenters decades ago. However, these are cheap, simple, and tiny. You only need a handful of components to make them work, and [Hans] shows you how to make the selection and what you need to think about when laying out the PC board. Check out the video below for a very detailed deep dive. To get the best performance, the PCB layout is at least as important as the components. [Hans] shows what’s important and how to best work out what you need using some online calculators. Using a NanoVNA and a USB spectrum analyzer, [Hans] makes some measurements on the devices using different components, which is very instructive. The measurements lined up fairly well with the theory, and you can see the effects of changing key c...

While Texas Instruments maintains dominance in the calculator market (especially graphing calculators), there was a time when this wasn’t the case. HP famously built the first portable scientific calculator, the HP-35, although its reverse-Polish notation (RPN) might be a bit of a head-scratcher to those of us who came up in the TI world of the last three or four decades. Part of the reason TI is so dominant now is because they were the first to popularize infix notation, making the math on the calculator look much more like the math written on the page, especially when compared to the RPN used by HP calculators. But if you want to step into a time machine and see what that world was like without having to find a working HP-35, take a look at [Jeroen]’s DIY RPN calculator . Since the calculator is going to be RPN-based, it needs to have a classic feel. For that, mechanical keyboard keys are used for the calculator buttons with a custom case to hold it all together. It uses two rows o...

YouTuber  The Science Furry  has been  attempting to make a split-anode magnetron  and, after  earlier failures, is having another crack at it. This also failed, but they’ve learned where to focus their efforts for the future, and it sure is fun to follow along. The magnetron theory is simple enough, and we’ve covered this many times, but the split anode arrangement differs slightly from the microwave in your kitchen. The idea is to make a heated filament the cathode, so electrons are ejected from the hot surface by thermionic emission. These are forced into a spiral path using a perpendicular magnetic field. This is a result of the Lorentz force . A simple pair of magnets external to the tube is all that is needed for that. Depending on the diameter of the cavity and the gap width, a standing wave will be emitted. The anodes must be supplied with an alternating potential for this arrangement to work. This causes the electrons to ‘bunch up’ as they cross the ...

Many of us are very heavy computer users, and two items that can affect our comfort and, by extension, our health are the keyboard and the mouse. We’ve covered many ergonomic and customisable keyboards over the years, but we are not sure we’ve covered a fully adjustable mouse until now. Here’s [Charlie Pyott] with their second take on an adjustable mouse, the open source, statial-b . [Charlie] goes into an extensive discussion of the design process in the video after the break, which is a fascinating glimpse into the methods used by a professional industrial designer. The statial concept breaks the contact surfaces of the mouse into fixed and moveable sections. The moveable sections are attached to the mouse core via a pair of ball joints connected with extendible arms, allowing the surfaces to be adjusted for both position and orientation. The design process starts with 3D scanning their ‘workhorse mouse,’ a Razer Deathadder Elite. This creates a reference volume within which the st...

It’s not news that Leonardo DaVinci was somewhat ahead of his time, and over the centuries many of the creations in his sketchbooks have been created and proved quite functional. The guys from the YouTube channel  How To Make Everything have been looking at one such sketch, a screw thread-cutting machine . At first glance, it seems a little flawed. Threads are hard to make by hand, and you can see that this thread-cutting machine needs two identical threads operating as a reference to make it work. However , as the guys demonstrate, you  can create threads by hand using simple methods . Starting with an offset blade mounted on a block with a hole through it, a dowel can be scribed with a starter thread. This can then be worked by hand to cut enough of a groove for the application. They demonstrated that the machine was viable using nothing but wood for construction. A metal blade was mounted, and some preload force was applied to it with a spring. The dowel to be cut was ...
